SUPER MICRO Computer X7SBL-LN1/LN2 User Manual
Page 37
Chapter 2: Installation
2-19
GLAN1
GLAN2
GLAN (Giga-bit Ethernet Ports)
Two G-bit Ethernet ports (GLAN1/
GLAN2) are located next to the VGA
Connector on the IO backplane. These
ports accept RJ45 type cables.
A. GLAN1
B. GLAN2
C. VGA
VGA Connector
A VGA connector (J16) is located
between COM1 and GLAN1 on the IO
backplane. Refer to the board layout
below for the location.
C
B
A
