12 GB
Connect the supplied speaker system using the supplied speaker cords by matching the colors of the
jacks to those of the cords. Do not connect any speakers other than those supplied with this system.
To obtain the best possible surround sound, specify the speaker parameters (distance, level, etc.) on
page 21.
Required cords
Speaker cords
The connector and the color tube of the speaker cords are the same color as the label of the jacks to be
connected.
To attach the foot pads
To prevent speaker vibration or movement while listening, attach the supplied foot pads to the center
speaker, as shown.
Step 1: Speaker System Hookup
(–)
(+)
color tube
(+)
(–)
