3-810-698-16(1)
1
Insert a cassette.
2
Set the FM/AM/TAPE
(RADIO OFF) selector to
TAPE (RADIO OFF).
3
Select NORM or CrO
2
/
METAL mode to match
the tape type.
4
Press
9 PLAY.
Playing Cassettes
FX325
FX323
FX325
T
APE
(RADIO OFF)
AM
FM
PLAY
AV L S
NORM
LIMIT
2
pSTOP
MODE
DIR
FM/AM/
TAPE(RADIO OFF)
VOLUME
NORM CrO
2/
METAL
0 )
9PLAY
Cassette holder
ON
OFF
M A
X
8
6
4 2 MIN
M A
X
8
6
4 2 MIN
HIGH
LOW
ON
OFF
Operating the Cassette Player
To wind the tape
Press
0 or ).
To change sides*
Set the DIR switch.
To play both sides once*
Set MODE to
Å.
To play both sides
Set MODE to
a.
repeatedly*
To adjust the volume
Turn the VOLUME control.
To stop
Press
p STOP.
* except for FX121/FX121V/FX127
Notes on playing cassettes
• Do not use cassettes longer than 90 minutes except for long
continuous playback.
• If the tape is playing but no sound comes out, the batteries
may be weak. Replace all dry batteries with new ones or
recharge all rechargeable batteries.
• If your Walkman has not been used for a long time, run the
Walkman for a few minutes before inserting a cassette.
• Do not wind the headphones cord around the Walkman.
The buttons may be kept pressed, causing unnecessary battery
usage.
• Do not open the cassette holder while the tape is running.
Using MEGA BASS (FX323/FX325)
Set the MEGA BASS switch to ON to produce deep and
powerful sound. Turn the HIGH and LOW controls to
get the desired tone (FX325).
When using MEGA BASS
If the AVLS switch is set to LIMIT, the MEGA BASS effect is
reduced.
Using DOLBY NR (FX325)
Set the DOLBY NR switch to ON to play Dolby NR
processed tapes.
ON
OFF
DOLBY NR
OWNER’S RECORD
The model number is located at the rear and the
serial number is located at the rear (FQ01)/inside the
cassette holder (other models).
Record the these numbers in the spaces provided below.
Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No.
Serial No.
Featuring
AVLS (Automatic Volume Limiter
System)
The AVLS switch allows you to limit the maximum volume of
your Walkman personal stereo without degrading the sound
quality.
•When the AVLS switch is set to LIMIT (around 85 dB), the
volume will be kept at a moderate level without the
degradation of the sound quality, even if you attempt to turn
the volume up higher.
•When the AVLS switch is set to LIMIT, the playback sound
may be distorted or unstable according to the music (especially
the bass boosted part). If this happens, turn down the volume.
•When the AVLS switch is set to NORM, you will be able to
enjoy the full volume capability of your Walkman personal
stereo.
Radio Cassette Player
WM
-
FX121/FX121V/FX127/FX321/
FX321V/FX323/FX325/FQ01
Operating Instructions
WALKMAN is a registered trademark of Sony Corporation.
Sony Corporation © 1996
Printed in Malaysia
For the customers in the U.S.A.
Getting Started
Using with Batteries
Insert two AA (R6) batteries in correct polarity.
AA (R6) x 2
DC IN 3V
Notes
•When you are not going to use your Walkman for a long time,
remove the batteries to prevent damage from battery leakage
and corrosion.
•When the sound becomes unstable or cannot be heard, replace
the old batteries with new ones.
•The battery life may shorten depending on the operation of the
unit.
Using External Power Sources
You can connect the following external power sources
through the DC IN 3 V jack located on the bottom. (When
you plug a cord into the DC IN 3 V jack, the internal
batteries are automatically bypassed.)
• House current using an AC-E30HG AC power adaptor
Notes
•Use only the recommended
AC-E30HG AC power adaptor (not
supplied). Do not use any other
AC power adaptor.
•Specifications for AC-E30HG varies for each area. Check your
local voltage and the shape of plug before purchasing.
Polarity of the plug
Using With a Rechargeable Battery
(FX127)
Before using, charge the rechargeable battery with the
supplied charger.
Charging time is about 4 hours.
After 4 hours, remove the batteries.
Open the battery
compartment lid
and insert the
rechargeable battery
after charging.
Notes
•The name plate indicating operating voltage, power consump-
tion, etc. is located on the bottom exterior of the charger.
•The battery may become warm during charging.
•Use only the rechargeable battery NC-AA (WM) with the
supplied battery charger.
•If the rechargeable battery is new or it has not been used for a
long time, it may not be charged completely. (The playing time
is shorter.)
•The rechargeable batteries can be charged about 300 times.
When using headphones/earphones
Wear the “L” marked side to the left ear and the “R”
marked side to the right ear.
NORM
CrO
2
/
METAL
