Safety warnings and Cautions

WARNING: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture.

CAUTION: To reduce the risk of electric shock, do not remove cover or back. No user serviceable parts

inside. Refer servicing to qualified personnel.

IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS

This manual contains important safety and operating instructions for your AC power adapter. Before using

your adapter, read all instructions and cautionary markings on the product.

DANGER: To reduce the risk of fire or electric shock, follow these instructions.

FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Your adapter is ETL listed to

UL standards and meets all applicable FCC standards.

WARNING: Changes or modifications to this unit not expressly approved by Sima may cause interference

and void the user’s authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:1. Re-orient or relocate the receiving antenna. 2. Increase the separation between the

equipment and receiver. 3. Consult Sima customer service at 800-345-7462 if the problem still exists.

CAUTIONS: ·The adapter must attach to the power supply source with a built-in over-current protective

device (Max. 15A), such as a 15A fuse and branch circuit.· Make sure the adapter is disconnected from the AC

outlet and device before adjusting the voltage setting.·Do not use the adapter to power a device that exceeds

the maximum power rating.·

Note: The SUP-70’s voltage must be the same as the voltage your portable device requires.·The SUP-70’s

current (mA) must be equal to or greater than the current your portable device requires.

Specifications:

AC adapter input: 120V AC, 60 Hz
AC adapter output: 13.5V DC, 1.2A

SUP-70 input:

12-15V DC,

Output rating:

3.3 / 4.2 / 5 / 6.5 / 8.4 or 9.5V DC

DC cord length: 1 m
Operation Temp: 32 to 113 degrees F
Storage temp.:

-4 to 140 degrees F

Dimensions:

4” x 2.1” x 1.4”

Plug #

Size (diameter)

4.0mm x 1.7mm

4.75mm x 1.7mm

Sony L/M

Sony S/C

3.5mm x 1.35mm

5.5 mm x 2.1mm

Sony FC

Brand

Model #

Voltage Plug #

AGFA

ePHOTO CL-30, CL-34, CL-50, 307, 780, 780C, 1280, 1680

6.5V

CANON

IXUS, IXUS V,V2, V3, 100, 110, 230, 300, 330

4.2V

CANON

A10, A20, A30, A40,

4.2V

CASIO

QV-10A, QV-11, QV-70, QV-100, QV-120, QV-200, QV-300, QV-700,
QV770, QV-780, QV-2000UX, QV-2300UX, QV-2400UX, QV-2800UX,
QV-2900UX, QV-3000EX, QV-3000Plus, QV-3500EX, QV-4000E,
QV-5000SX, QV-5500SX, QV-7000SX, QV-8000SX

6.5V

EPSON

PC 550, PC 600, PC 650, PC 700, PC 750Z, PC800Z, PC850Z, PC2100Z,
PC3000Z, PC3100Z

6.5V

FUJIFILM

Finepix 50i,1300, 1400Z, 2300, 2400Z, 2700Z, 2800Z, 2900, 3800, 4800Z,
4900Z, 6800Z, 6900Z, DX-10, F401, F402, F601, M603, MX-500, MX-600Z,
MX-700, MX-1200, MX-1400, MX-1500, MX-1700Z, MX-2700, MX-2900Z,
S1 Pro, S2 Pro, S304, S602,S3100

PhotoSmart 120, 315, 318, 320, 612, 620, 720, 850

6.5V

KODAK

DC40, DC50, DC120, DC200, DC200 plus, DC210, DC210 plus, DC215,
DC220, DC240, DC240i, DC260, DC265, DC280, DC290, DC3200z,
DC3400z, DC5000z

6.5V

KODAK DC4800, LS443, DX7440, DX7590, DX7630, LS743

KYOCERA Finecam S3, S3L, S4, S5

MINOLTA

Dimage 5, 7, 7Hi, 7i, 3D 1500, EX1500, 2300, 2330z, E201, RD3000,
S304, S404

6.5V

NIKON

Coolpix 100, 300, 600,700, 750, 800, 900, 950, 990, 2000

6.5V

NIKON

CoolPix 775, 880, 885, 995, 4300, 4500, 5000, 5700,8700

8.4V

OLYMPUS

C-100, C-120, C-200Z, C-211, C-300Z, C-320L, C-700UZ, C-720UZ,
C-730UZ, C-960Z, C-990Z, C-2000Z, C-2020Z, C-2030, C-2040Z,
C-2100Z, C-2500L, C-3000Z, C-3020Z. C-3030Z, C-3040Z, C-4000Z,
C-4040Z, C-5050Z, D-200L, D-220L, D-320L,D-340L, D-340R, D-360L,
D-370L, D-400Z, D-450L, D-450Z, D-460Z, D-500L, D550Z, D-600L,
D-620L, E-10, E-20, E-20P, E-100 RS

6.5V

OLYMPUS

C-1, C-1Z, C-2, C-40Z, C-220Z, D-40Z, D-100, D-150Z, D-230,D-395, D-580
D-540

3.3V

OLYMPUS

C-50Z

4.2V

OLYMPUS

Stylus 300, Stylus 410

4.8V

PANASONIC DMC-F7

PANASONIC DMC-FZ1

8.4V

PANASONIC DMC-LC5, DMC-LC40

8.4V

PENTAX

Optio 330RS, 430RS

4.2V

PREMIER

DC620, 820, 1310, 1311, 1500, 2000

6.5V

RICOH

Caplio PR1, Caplio PR10, Caplio PR120, RDC-2, RDC-2E, RDC-300,
RDC-300Z, RDC-4200, RDC-4300, RDC-5000, RDC-5300, RDC-6000,
RDC-7, RDC-i500, RDC-i700

SANYO

VPC-MZ1, VPC-AZ1

3.3V

SIMA

CP-150 Image Bank (Digital Photo Storage Unit)

6.5V

SONY

CD200, CD250, CD300, CD400, CD450, CD1000, F707, F717, FD85,

8.4V

FD87, FD90, FD92, FD95, FD97, FD100, FD200, S50, S70, S75, S85

SONY

P1, P2, P3, P5, P9, P20, P30, P31, P50, P51, P71

4.2V

SONY

Cybershot DSC P4, P8, P10, P32, P52, P72, P-73, P92, P93, V-1, W-1,

4.2V

SONY

F-828

4.2

TOSHIBA

PDR-M1, M3, M4, M5, M11, M21, M25, M60, M61, M65, M70, M71, M81

Digital Camera/Camcorder SUP-70 Connector Plug Chart

Sima Products Corporation 140 Pennsylvania Ave. Bldg #5

Oakmont, PA 15139 USA 800-345-7462 www.simacorp.com

Made in Tawa n

PN21713
