Adjustments

M414905

56

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Figure 26

T041I

1

Airflow Switch

6

Switch Lever

2

Mounting Bracket

7

Spring Clip

3

Rear Panel of Tumbler

8

Counterweight

4

Switch Mounting Screws

9

Disc

5

Screw

10

Vane Lever Arm

T041I

9

1

8

6

7

9

8

7

6

5

3

10

2

4

10
