Sunrise Medical Trek 3 - Manual (Page 21)

930490 Rev. A
I X . S e t - U p , A d j u s t m e n t & U s e 21 E n g l i s h
D. SEAT REMOVAL (Figure 5)
1. Lift red lever on right side of seat (A).
2. Lift seat off.
E. SEAT SWIVEL (Figure 6)
1. Lift red lever on right side of seat (A).
2. Swivel seat to desired position.
3. Release red lever when seat clicks into one of four swivel positions.
F. SEAT HEIGHT ADJUSTMENT (Figure 7)
1. Remove seat and lift off battery case to access the seat post pin.
2. Remove pin (B) from seat post.
3. Move the post up or down to select the desired seat height.
4. Reinsert the seat post pin.
G. BASKET INSTALLATION AND REMOVAL (Figure 8)
1. To install the basket, place the openings in the back of the basket over the hooks on
the front of the tiller as shown.
2. To remove, lift the basket up and off the hooks.
5
6
A
A
7
B
8
