D-NE050_2-685-477-11(1)_GB
WARNING
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
Do not install the appliance in a confined space, such as a
bookcase or built-in cabinet.
To reduce the risk of fire, do not cover the ventilation of the
apparatus with newspapers, tablecloths, curtains, etc. And do not
place lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do not place objects
filled with liquids, such as vases, on the apparatus.
CAUTION
The use of optical instruments with this product will increase eye
hazard.
Certain countries may regulate disposal of the battery used to
power this product. Please consult with your local authority.
The validity of the CE marking is restricted to only those countries
where it is legally enforced, mainly in the countries EEA (European
Economic Area).
For customers who purchased this product in the USA
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for
help.
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
Portable CD Player
Operating Instructions
2-685-477-
11 (1)
©2006 Sony Corporation Printed in China
D-NE050
Printed on 100 % recycled
paper using VOC (Volatile
Organic Compound)-free
vegetable oil based ink.
Discs Playable on this CD
Player
•
Audio CDs
(CD-DA format CDs)
•
MP3 CDs
(CD-R/CD-RW on which audio data compressed in
the MP3 format has been recorded)*
* Only ISO 9660 Level 1/2 and Joliet extension format discs can
be played.
Bit rates and sampling frequencies this CD player can play are as
follows. Variable Bit Rate (VBR) files can also be played.
Bit rates
Sampling frequencies
MPEG-1 Layer3
32 – 320 kbps
32/44.1/48 kHz
MPEG-2 Layer3
8 – 160 kbps
16/22.05/24 kHz
MPEG-2.5 Layer3 8 – 160 kbps
8/11.025/12 kHz
MP3 CDs
The usable number of groups and files
• Maximum number of groups: 256
• Maximum number of files: 512
Playing order
The playing order may differ depending on the method used to
record MP3 files on the disc. In the following example, files are
played in order of 1 to 7.
MP3
Group
File
(Maximum directory levels: 8)
Notes
• Depending on the quality of the disc and/or the condition of the
recording device, it may take a while for playback to start. It is
also possible playback may not start at all.
• On a disc that has MP3 files, do not save files in other formats
and do not make unnecessary folders.
• Be sure to add the file extension “mp3” to the file name.
However, if you add the extension “mp3” to a file other than
an MP3 file, the player will not be able to recognize the file
properly.
• To compress a source in an MP3 file, we recommend setting
the compression parameters to “44.1 kHz,” “128 kbps,” and
“Constant Bit Rate.”
• To record up to the maximum capacity, set the writing software
to “halting of writing.”
Remaining battery power
Sound mode
Track number
Playing time
Play mode
Bookmark
* The button has a tactile dot.
Display
*(play/pause)
DC IN 4.5 V
(headphones) jack
(stop)
HOLD (rear)
VOL +*/–
to an AC outlet
AC power adaptor
Headphones
SOUND/AVLS
/•
(group) –/+
P MODE/
OPEN
GROUP
MP3 indicator
Group indicator
“WALKMAN”,
, and
are registered trademarks of Sony Corporation.
Power Sources
To use the batteries (not supplied)
1
Slide OPEN to open the player lid and open the battery
compartment lid inside the CD player.
2
Insert two LR6 (size AA) alkaline batteries by matching the
to the diagram inside the CD player and close the lid until it
clicks into place. Insert the
end first (for both batteries).
Battery life* (approx. hours)
(When the CD player is used on a flat and stable place.)
Playing time varies depending on how the CD player is used.
When using two Sony alkaline batteries LR6 (SG)
(produced in Japan)
G-PROTECTION
G-on G-off
Audio CD
16
11
MP3 CD (Recorded at 128 kbps)
23
23
* Measured value by the standard of JEITA (Japan Electronics and
Information Technology Industries Association).
• The indicator sections of
roughly show the remaining
battery power. One section does not always indicate one-fourth
of the battery power.
To use the AC power adaptor (not supplied)
Connect the AC power adaptor as illustrated.
Playing a CD
1
Slide OPEN to open the lid and fit the CD to the pivot, then
close the lid.
2
Press
.
To play from the first track, press and hold
until playback
starts while the CD player is stopped.
To jump to the succeeding/previous groups*, press GROUP
first, then press
+ or
–. *MP3 CD only
• This CD player can play CD-Rs/CD-RWs recorded in the
Compact Disc Digital Audio (Audio CD) format, but playback
capability may vary depending on the quality of the disc and
the condition of the recording device.
• This product is designed to play back discs that conform to
the Compact Disc (CD) standard.
Recently, various music discs encoded with copyright
protection technologies are marketed by some record
companies. Please be aware that among those discs, there are
some that do not conform to the CD standard and may not be
playable by this product.
• Depending on the CD, this player may display a total
number of files that includes both playable and unplayable
files. However, because the player skips unplayable files
automatically, only the playable ones will be played.
Note on DualDiscs
A DualDisc is a two sided disc product which mates DVD
recorded material on one side with digital audio material on
the other side. However, since the audio material side does not
conform to the Compact Disc (CD) standard, playback on this
product is not guaranteed.
Digital MEGA BASS function
During play, press SOUND/AVLS repeatedly to select “SND 1”
or “SND 2.”
If the sound is distorted, turn down the volume.
AVLS* function
*Automatic Volume Limiter System
Press and hold SOUND/AVLS.
If “AVLS” flashes three times, the function is enabled.
If “AVLS” flashes once, the function is disabled.
AMS* / search function
*Automatic Music Sensor
To find the beginning of the previous/current/next/succeeding
track(s): Press
/ repeatedly.
To go backward/forward quickly: Press and hold
/.
Play mode function
During play, press P MODE/
repeatedly:
No indication (normal play)
“
(group play)”
1)
“1”(single
track play)
“SHUF”(shuffle play) “
SHUF (group
shuffle play)”
2)
“ ”(Bookmark play)
To repeat the play mode you selected, press and hold P MODE/
until “
” appears.
1)
All files in the selected group are played once. MP3 CD only.
2)
All files in the selected group are played once in random order.
MP3 CD only.
G-PROTECTION function
The function provides protection against sound skipping during
many active uses.*
The default setting is “G-on.” To select “G-off,” press
while
you keep pressing
during stop. To enjoy high quality CD
sound, select “G-off”.
* Sound may skip: if the CD player receives stronger continuous
shock than expected / if a dirty or scratched CD is played / when
using poor-quality CD-Rs/CD-RWs or if there is a problem with
the recording device or application software.
Bookmark play
If you add Bookmarks to your favorite tracks, you can listen to
these tracks only from the track with the lowest number.
1
During playback of the track where you want to add a
Bookmark, press and hold
until “
(Bookmark)” flashes
on the display.
2
Repeat step 1 to add Bookmarks to the tracks you want.
3
Press P MODE/
repeatedly until “
” flashes.
4
Press
.
To remove the Bookmarks
During playback of the track with a Bookmark, press and hold
until “
” disappears from the display.
If you change CDs and start playing, all the bookmarks added for
the previous CD will be erased.
Precautions
On safety
• Should any solid objects or liquid fall into the CD player, unplug
it and have it checked by qualified personnel before operating it
any further.
• Do not put any foreign objects in the DC IN 4.5 V (external
power input) jack.
On power sources
• When you are not using the CD player for a long time,
disconnect all power sources from the CD player.
On the AC power adaptor
• Use only the AC power adaptor supplied.
If your player is not supplied with an AC
power adaptor, use an AC-E45HG AC power
adaptor*. Do not use any other AC power
adaptor. It may cause a malfunction.
* Not available in Australia and some other
regions. Ask your dealer for detailed
information.
Polarity of the
plug
• Do not touch the AC power adaptor with wet hands.
• Connect the AC power adaptor to an easily accessible AC outlet.
Should you notice an abnormality in the AC power adaptor,
disconnect it from the AC outlet immediately.
On dry batteries
• Do not throw the batteries into fire.
• Do not carry the batteries with coins or other metallic objects.
It can generate heat if the positive and negative terminals of the
battery are accidentally contacted by a metallic object.
• Do not mix new batteries with old ones.
• Do not use different types of batteries together.
• When the batteries are not to be used for a long time, remove
them.
• If battery leakage occurs, wipe off any deposit in the battery
compartment, and install new batteries. In case the deposit
adheres to you, wash it off thoroughly.
On the CD player
• Keep the lens on the CD player clean and do not touch it. If
you do so, the lens may be damaged and the CD player will not
operate properly.
• Do not put any heavy object on top of the CD player. The CD
player and the CD may be damaged.
• Do not leave the CD player in a location near heat sources, or
in a place subject to direct sunlight, excessive dust or sand,
moisture, rain, mechanical shock, unleveled surface, or in a car
with its windows closed.
• If the CD player causes interference to the radio or television
reception, turn off the CD player or move it away from the radio
or television.
• Discs with non-standard shapes (e.g., heart, square, star) cannot
be played on this CD player. Attempting to do so may damage
the CD player. Do not use such discs.
On headphones
Road safety
Do not use headphones while driving, cycling, or operating any
motorized vehicle. It may create a traffic hazard and is illegal
in some areas. It can also be potentially dangerous to play your
headsets at high volume while walking, especially at pedestrian
crossings. You should exercise extreme caution or discontinue use
in potentially hazardous situations.
Preventing hearing damage
Avoid using headphones at high volume. Hearing experts advise
against continuous, loud and extended play. If you experience a
ringing in your ears, reduce volume or discontinue use.
Consideration for others
Keep the volume at a moderate level. This will allow you to hear
outside sounds and to be considerate to the people around you.
To clean the plugs
If the plugs become dirty, there is no audio or noise is heard. Clean
them with a dry soft cloth periodically.
Troubleshooting
Should any problem persist after you have made these checks,
consult your nearest Sony dealer.
“Hold” appears in the display when you press a button, and
the CD does not play.
The buttons are locked. Slide HOLD back.
The volume does not increase even if you press VOL +
repeatedly.
Press and hold SOUND/AVLS until “AVLS” flashes once so that
you can cancel the AVLS function.
The CD player does not operate properly.
Moisture condensation has occurred. Leave the player aside for
several hours until the moisture evaporates.
Even though the file number is displayed, the player skips
the file and does not play it.
A file with a format that is unplayable on this player is recorded
on the CD.
Specifications
System
Compact disc digital audio system
Laser diode properties
Emission duration: Continuous
Laser output: Less than 44.6 µW (This output is the value
measured at a distance of 200 mm from the objective lens surface
on the optical pick-up block with 7 mm aperture.)
Power requirements
• Two LR6 (size AA) batteries: 1.5 V DC × 2
• AC power adaptor (DC IN 4.5 V jack):
220 V, 50 Hz (Model for China)
120 V, 60 Hz (Model for Mexico)
Dimensions (w/h/d) (without projecting parts and
controls)
Approx. 139.8 Ч 29.0 Ч 139.8 mm (5 5⁄8 Ч 1 3⁄16 Ч 5 5⁄8 in.)
Mass (excluding accessories)
Approx. 203 g (7.2 oz.)
Operating temperature
5°C - 35°C (41°F - 95°F)
MPEG Layer-3 audio coding technology and patents
licensed from Fraunhofer IIS and Thomson.
Design and specifications are subject to change without notice.
Supplied accessories
Headphones (1)
