SECO-LARM USA Enforcer E-942FC-1K3SQ User Manual
80 pound mini electromagnetic lock, Miniature size, 2 / ” x ” x 1
Installation:
Technical Specifications:
Low current drain.
Dual voltage: 12 or 24 VDC.
No residual magnetism.
Detachable mounting bracket.
MOV surge protection.
Mounting hardware included.
1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: 1.949.261.7326
Email: [email protected] Website: www.seco-larm.com
16842 Millikan Avenue, Irvine, CA 92606
GateLockg.cdr
80 Pound Mini
Electromagnetic Lock
Dimensions:
E-942FC-1K3SQ
Power
Magnet Size
Armature Size
Holding Force
Current Drain
Voltage Tolerance
Housing
Temperature
Weight
12~24VDC
3
2 /
4
x 1 x
in. (70 x 31 x 20 mm)
2 x 1 x
in. (60 x 31 x 9 mm)
80 lb. (36kg.) @ 12VDC
110lb. (51Kg.) @ 24VDC
85mA @ 12VDC
165mA @ 24VDC
± 10%
Aluminum
14°F to 131°F (-10°C to 55°C)
0.90 lb. (410 grams)
1
13
/
4
/
16
3
1
23
/
8
/
4
/
64
Features:
Miniature Size:
3
2 / ” x ” x 1 ”
4
For spaces where small size is required,
including cabinets, drawers, etc.
3
1
/
/
4
4
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
Copyright 2008 SECO-LARM U.S.A., Inc. All rights reserved.
E-941SA-80Q
Armature Plate
2
3
/
8
" (60mm)
2
3
/
4
" (70mm)
3
/
4
" (19mm)
3
/
8
"
(9mm)
1
/
4
"
(4.5mm)
1
1
/
4
"
(31mm)
1
(31mm)
1
/
4
"
Sexnut
bolt
This side drill
9mm only
Drill a 5mm
hole thru door
Armature
Screw
Steel and
Rubber
washers
(as
needed)
Armature
HOLLOW METAL DOOR
Drill an 5mm hole thru door. From sexnut
bolt side only, enlarge the 5mm hole to9mm.
Drill an 5mm hole thru door. From sexnut
bolt side of door, drill 9mm (23/64") hole,
25mm in depth.
Drill a 3.5mm dia. hole and tap for
M5 x 0.8 thread.
Sexnut
bolt
Drill 9mm
(23/64")
Drill a 5mm
hole thru door
Armature
Screw
Armature
SOLID CORE DOOR
Armature Screw
Tap M5 x 0.8 Thread
REINFORCED DOOR
Armature
Steel and
Rubber washers
(as needed)
Steel and
Rubber washers
(as needed)
L-shaped
Maounting
bracket
Magnet
Sexnut
bolt
Armature Plate
Steel and Rubber washers
STANDARD MOUNTING
