IIKKEELLIITTEE VVIID DEEO O CCAASSEE
SSU UPPPPLLEEM MEEN NTTAALL IIN NSSTTRRU UCCTTIIO ON NSS FFO ORR
SSoonnyy DDCCRR H HCC
This supplemental set of instructions describes additional features specific to your
housing model Prior to testing the system in the water please read this supplement
along with the general instruction manual to become familiar with its features and
functions
Ikelite Video Cases are slightly negative in salt water for stability This housing has
been water pressure tested at the factory and has a working depth of m ( ')
H HO OU USSIIN NGG CCO ON NTTRRO OLLSS ________________________________________________________________________________________________________________
• Power On/Off / Mode
• Start/Stop
• Power Zoom
• Photo
• Flash
• Back Light / Display info/
Easy Operation
• Wide Select
M MAAIIN N O O RRIIN NGG ______________________________________________________________________________________________________
O rings last several years if properly maintained Control seals should not need
to be replaced as long as the control shafts are kept clean and lightly lubricated
Port
Base
Bottom Bar
Photo Eyeport
Power/
Mode
Start/
Stop
Power Zoom
Wide Select
Flash
Back Light/Display/Easy Operate
PP RR EE PP AA RR AA TT II O O N N
PPAACCKKAAGGEED D W WIITTH H H HO OU USSIIN NGG__________________________________________________________________________________________
• External UR/Pro Color Filter
• Silicone Lubricant
CCO OLLO ORR FFIILLTTEERR__________________________________________________________________________________________________________________
The installation and usage of the external UR/Pro color filter is described in the
general instruction manual
O OPPTTIIO ON NAALL W WIID DEE AAN NGGLLEE LLEEN NSS____________________________________________________________________________________
The lens port on the front of the housing accepts the optional wide angle lenses
offered by Epoque (DCL ) Inon (UWL Type ) and the discontinued Sea&Sea
( ) These waterproof lenses secure to the outside of the lens port and are not
marketed by Ikelite
Should you elect to use the optional Epoque Inon or Sea&Sea lens carefully thread
the waterproof lens on the front of the lens port The lens threads are very fine;
D DO O N NO OTT cross thread It should screw on very easily If it is difficult to turn you are
cross threading
There is another optional wide angle lens which secures directly to the front of
the camera lens inside the housing It is the optional X conversion wide angle lens
VCL S by Sony Although this lens is now discontinued by Sony you still may be
able to locate this lens from a supplier of Sony products Note that you MUST also
replace the original lens port on the housing with the required Ikelite extended lens port
in order to use the optional Sony wide angle lens inside the housing
External
Color Filter
