Washer-Extractors
5-08-51
67
Mounting Bolt Hole Locations - Model IWF055 (M-speed)
CHM2170N
Figure 40
CHM2170N
3.54 in.
(90 mm)
26.77 in. (680 mm)
1.97 in.
50 mm)
1.97 in.
(50 mm)
11
.1
in.
(282 m
m
)
35.
43 i
n
. (900
m
m
)
20.
39 in.
(
518 mm
)
3.54 in.
(90 mm)
33.86 in. (860 mm)
ø1.06 in.
(ø27 mm)
