Server System Chassis and Assemblies
Intel® Server Platform SR6850HW4 TPS
Revision
1.0
Intel order number D23151-001
24
Figure 6. Server Platform SR6850HW4 Rack and Pedestal Configurations
Figure 7. Server Platform SR6850HW4, Bezel and Top Cover Removed
Memory Modules
PCI Adapter Slots
Slide Rail Mount Points
(both sides of chassis)
