INFINITY M
INFINITY L
22
Figure 4
INFINITY WITH UPPER REAR PANEL REMOVED
Rear Insulating Panel
Thermocouple
Thermocouple Clamp
Ceramic Insulating
Bushing
Insulating Filler
Heating Plate Wire
Power Terminal
Heater (Power) Leads
Jumper
Heating Plate Wire
Power Terminal
Heater (Power) Leads
Jumper
Insulating Filler
Ceramic Insulating
Bushing
Thermocouple Clamp
Thermocouple
Rear Insulating Panel
