Notes:
1. An environment can have a library manager without a library client.
2. In an environment where ACSLS library support is required, the library client
can reside on a Tivoli Storage Manager server on AIX, Linux, HP-UX, Solaris,
Windows, or z/OS. The library manager must reside on a Tivoli Storage
Manager server on AIX, Solaris, or Windows.
The configurations in Figure 3 are the following:
v A Tivoli Storage Manager server library manager manages a client’s data, which
is stored on a tape library.
v A Tivoli Storage Manager server library client manages a client’s data, which is
stored on a tape library.
LAN
SAN
Tivoli Storage Manager
Clients with Storage Agents
Tivoli Storage Manager
Server Library Client
Tape Library
Tivoli Storage Manager
Server Library Manager
Figure 3. Library Manager and Client LAN-free Configuration
Chapter 2. Planning 7
