650710ĆC
PARTS LIST / FLUID SECTION
d NOTE: Radius edge of parts (5 and 6) is against diaphragm.
Figure 1
. TORQUE REQUIREMENTS ,
LUBRICATION / SEALANTS
k
Apply KeyĆLube to all O" rings, U" Cups & mating parts.
H Apply gasolineĆresistant pipe sealant to pipe threads.
NOTE: DO NOT OVERTIGHTEN FASTENERS
(14) Diaphragm Bolt, apply Loctite 271 to threads and tighten to
65 Ć 70 ft lbs (88.1 Ć 94.9 Nm).
(26, 29) Fluid Cap / Manifold nuts and bolts 120 Ć 140 in. lbs (13.6 Ć 15.8 Nm).
COLOR CODE
DIAPHRAGM BALL
MATERIAL COLOR
COLOR
ACETAL
N / A
Orange
NITRILE
Red (-)
N / A
(-) Stripe
FLUID
SIDE
AIR
SIDE
CROSS SECTION VIEW OF DIAPHRAGMS
5
7
2
3
4
1
8
6
Torque Sequence
10
9
1 k
29 ,
FOR THE
AIR MOTOR SECTION
SEE PAGES 6 & 7
Tab
7
k 3
21
19 k
22
26 ,
16
59
15
22
21
19 k
16
27
32
14 ,
9
6
5
2 k
3 k
26 ,
93130
H
H
H
