Figure 6-2 – Intel SGI Altix 450 User Manual
Page 134
112
007-4857-002
6: Maintenance and Upgrade Procedures
3.
Be careful not to snag the ribbon cable while replacing the panel.
4.
Use the T10 torx driver to tighten the retention screw holding the panel to the IRU.
5.
Restart the IRU or system as applicable.
Figure 6-2
Replacing the L1 Controller Panel
inside
TM
inside
TM
B
C
Tighten screw
inside
TM
A
