O Oppttiioonnaall AAcccceessssoorriieess ((ccoonntt..))
EV-controller
SSttrroobbee PPaacckkaaggeess
#3944.54 Substrobe DS-51 package includes #4086.61 Arm System
(page #11) and EV Manual Controller.
#3944.91 Substrobe DS-160 package includes #4086.61 Arm
System (page #11), 1.5 hour Smart Charger, and EV Manual
Controller
connect to
DS-Substrobe
mount to
Extended
Stem Mount
(page #11)
N Noottee::
DS Strobes must be set to “TTL” to utilize the manual
power settings on the EV Manual Controller.
EEVV M Maannuuaall CCoonnttrroolllleerr
Provides 10 manual power
settings in half-stop
increments for SubStrobe
DS-50, DS-51, DS-80,
DS-125, DS-160 and
DS-200 models.
Simply point the
Controller at your camera
housing for dependable
strobe triggering by the
camera strobe.
The Controller attaches to
the strobe and mounts
near the housing on the
#9571.3 Extended Stem
Mount (Page #11).
Test
Off
On
On
w/Lite
TTL Full Fuel
Guage
Ready Light
3
2
1
-2
-3
-4
-1
DS DS
SUBSTROBE
160
SSuubbssttrroobbee D DSS116600
The Substrobe DS160 covers
the equivalent of an 18mm
lens or 100 degrees
w/diffuser installed. It is the
ideal choice when using
accessory wide angle lenses
greater than 28mm. It also
features a 1.5 second recycle
time and 225 flashes per full
charge.
Substrobe
DS160
SSAA--110000 BBaallll//SSoocckkeett AArrm m
The SA-100 system #4086.61
with its 1" diameter ball is ideal
underwater. The #9571.3
extended stem mount allows
easy attachment of the EV-
controller or flashlight mount,
and drops right into the release
handle. Aim does not change
when changing the aim of the
strobe. The arm system allows
easy strobe placement from
macro close-up to wide angle
without changing aim of the
Sensor. The complete system
removes with a push of the
handle button.
SA-100 Ball/Socket
Arm #4086.61
#9571.3 Extended
Stem Mount (included
with SA-100
Ball/Socket arm)
ikelite
O Oppttiioonnaall AAcccceessssoorriieess ((ccoonntt..))
SSuubbssttrroobbee D DSS5511
The Substrobe DS51 covers the
equivalent of a 28mm lens. It is
the ideal choice when using only
the camera lens with no accessory
wide angle lenses attached.
ikelite
SUBSTROBE
DS
51
ikelite
Substrobe
DS51
D DSS D Diiggiittaall SSttrroobbeess
For the best underwater photographic results, we recommend
adding an external DS-digital strobe and EV-controller, connected
to the housing with a SA-100 Ball/socket arm.
Ikelite DS series Substrobes are industry favorites for their warm,
even coverage and lightning fast recycle time. Being farther from
the camera lens, the optional DS Substrobe aids in reducing the
illumination of particles in the water and helps to eliminate
backscatter.
When used in conjunction with the EV-Controller, the DS51 Mode
switch is set to the TTL setting and the EV-Controller provides ten
power settings in half-stop increments.
O Oppttiioonnaall AAcccceessssoorriieess ((ccoonntt..))
GGrreeeenn W
Waatteerr FFiilltteerr
# #66444411..8811
Enhances contrast and alters the color of green water to give
your subject a rich, natural tone. For available light only and
not recommended for use with flash.
TTrraayy w wiitthh D Duuaall RReelleeaassee H Haannddlleess
# #99552233..3322
Dual Tray and Release Handles are required to mount two
external Substrobes.
D Diiffffuusseerr
The diffuser should be installed when using the camera’s built
in flash. When shooting with the camera’s built-in flash at
approximately 2 feet (0.6 m) or less, the lens port on the
housing may block a portion of the light from the camera’s
built-in flash, creating a shadow in the lower area of the photo.
If this occurs, zoom the lens slightly to eliminate the shadow.
(You can test this above water)
D Deefflleeccttoorr
The deflector should be installed when using an external strobe
such as the DS51 or DS160 Substrobe with an EV Controller. The
deflector will redirect the camera’s flash to the EV Controller
which controls the external DS strobe’s output.
LLeennss PPoorrtt
Treat the glass in the lens port as a camera lens. After use, rinse
and gently dry the lens port to avoid water spotting. To clean,
use a mild soap solution or lens cleaner. N NO OTTEE:: The lens port
contains 67mm external threads to accept 67mm accessory
lenses (see page #13).
Do not use alcohol or window cleaner on the Lens Port.
O Oppttiioonnaall AAcccceessssoorriieess
BBaacckk oo--rriinngg
# #00111100
O-rings last for several years if properly maintained. (See
maintenance section). Always carry a spare o-ring in case the
original becomes damaged or lost.
U URR//PPrroo FFiilltteerr ((BBlluuee W Waatteerr))
# #66444411..4411
The UR/Pro underwater color correcting filter is designed to
restore some of the warm colors filtered out by the water. For
available light use only and not recommended for use with
flash.
