ZEROING THE METER
Turn the meter on with the sensor cap in place over the light sensor. The value
should read 000 in any range. If the meter does not read 000, adjust 0 ADJ
with a small screwdriver until the reading indicates 000.
SPECIFICATIONS:
Display 2000 count LCD display
Sensor Silicon photodiode and filter
Measuring Range
200,2000, 20000,200000 Lux
20,200,2000,20000 Footcandles
Accuracy
±3% (Calibrated to standard incandes-
cent lamp 2856°K)
8% all other visible light sources
Angle deviation from
cosine characteristics
30° ±2%
60° ±6%
80° ±25%
Power Supply
9V NEDA 1604, IEC 6F22, JIS 006P
battery x 1pc
Battery life Approximately 200 hours
Dimensions
Meter: 1.5 (H) x 2.2 (W) x 5.1 (L) in.
38 (H) x 55 (W) x 130 (L) mm
Sensor 9.8 (H) x 2.2 (W) x 3.1 (L) in.
25 (H) x 55 (W) x 80 (L) mm
Weight Approx. 8.8 oz. (250 g) with battery
Accessories User’s manual,carrying case, 9V battery
Length of cable for light sensor: Approx. 4.92 ft. (1.5M)
