■ Specifications
• GENERAL
• Frequency coverage :
Transmit 156.025–157.425 MHz
Receive 156.025–162.025 MHz
• Mode : FM (16K0G3E)
• Channel spacing : 25 kHz
• Current drain (at 13.8 V) : TX high 6.0 A max.
Max. audio 1.2 A max.
• Power supply requirement : 13.8 V DC
• Frequency stability : ±10 ppm
(–20°C to +60°C; –4°F to +140°F)
• Dimensions : 165(W) ×110(H)×109.4(D) mm
(Projection not included)
• Weight : 1130 g
• TRANSMITTER
• Output power : 25 W and 1 W
• Modulation system : Variable reactance phase
modulation
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than 0.25 µW
• RECEIVER
• Receive system : Double conversion superheterodyne
• Sensitivity (12 dB SINAD) : Less than 0.32 µV (typical)
• Squelch sensitivity : Less than 0.32 µV
• Intermodulation rejection ratio : More than 68 dB
• Spurious response rejection ratio: More than 70 dB
• Adjacent channel selectivity : More than 70 dB
• Audio output power
: 3.5 W at 10% distortion with a 4 Ω
load
■ Options
• DS-100 DSC CONTROLLER
When the DS-100 is installed, the transceiver conforms to
DSC class D for marine digital communications.
• MB-75 FLUSH MOUNT
For mounting the transceiver to a panel.
• SP-5 EXTERNAL SPEAKER
A large, external speaker for superior audio output.
• SP-10 EXTERNAL SPEAKER
A compact, external speaker. Features easy installation.
• UT-98 VOICE SCRAMBLER UNIT
• UT-112 VOICE SCRAMBLER UNIT
Ensures private communications. 128 or 32 codes are avail-
able. Not available in some countries.
10
SPECIFICATIONS AND OPTIONS
25
All stated specifications are subject to change without notice or
obligation.
