11
Cut out dimensions
(see chapter “Building In”)
Width:
560 mm
Depth: 480 mm
Overall dimensions
Width: 594 mm
Depth: 510 mm
Technical data
Heat Input
Triple Crown burner 4,0 kW
Semi-rapid burner 2,0 kW
Auxiliary burner 1,0 kW
Electric supply: 230 V ~ 50 Hz
Category: II2H3+
Gas supply: LPG 28-30 / 37 mbar
Appliance class 3
BURNER NORMAL REDUCED NORMAL POWER
POWER POWER
kW kW NATURAL POWER LPG
28-30/37 mbar
m 3 /h g/h
inj.
G20
inj.
G30 G31
100/mm 20 mbar 100/mm
Auxiliary 1,0 0,33 70 0,095 50 73 71
Semi-rapid 2,0 0,45 96 0,190 71 145 143
Triple crown 4,0 1,2 146 0,381 98 291 286
By-pass diameters
Burner Ø By-pass in 1/100 mm.
Auxiliary 28
Semi-rapid 32
Triple crown 56
