KPC Series
Specification
Model Name KPC1200 KPC1500 KPC1700 KPC1900
Motherboard B78
CPU Supports Intel Celeron M 1.3 / 1.5GHz; Pentium M 1.8GHz
Chipset Intel 852GM and ICH4 FSB 400Mhz
System Memory 2 x DDR SO-DIMM slot, up to 2 GB
Graphic Memory Share system memory max 64MB
LCD / Touch Panel
LCD Size 12" TFT LCD 15" TFT LCD 17" TFT LCD 19" TFT LCD
Brightness 400nits 350nits 300nits 300nits
Maximal Resolution 800 x 600 1024 x 768 1280 x 1024
Touch Screen Type Resistive touch Resistive type / SAW touch / IR Touch
Storage
HDD 2.5" Slim HDD bay
Flash Memory Optional Compact Flash memory (without HDD)
Expansion
mini-PCI Slot 1 x support 802.11 a/b/g WLAN card
PCI express 1 for B98 main board only
External I/O Ports
USB 2.0 4 x USB Type A
Serial / COM RJ-45 (COM1 standard RS-232; COM2 RS-232 / 422 / 485 selectable by jumper; COM3 & COM4 pin 9 with 5V
or 12V power by jumper)
Parallel 1 x D-sub 25F
LAN (10 / 100) 1 x RJ-45
Cash Drawer 1 x RJ-11 (12V or 24V)
DC Jack 1 x Latch Type
Audio Jack 1 x MIC-in, 1 x Speak-out
2nd VGA 1 x DB 15F
Internal Interface
USB 2.0 2
Audio
Speaker 1 x 3W Speaker 2 x 3W Speakers
Power
Power Adapter DC 19V / 90W
Environment
EMC & Safety FCC Class A, CE, LVD
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20° ~ 60°C (-4°F ~ 140°F)
Operating Humidity 5% - 95% RH non-condensing
Storage Humidity 5% - 95% RH non-condensing
Dust & Water Proof NEMA 4 / IP 65 (front)
Dimension (W x D x H) 331 x 265 x 55 mm 386 x 308 x 60 mm 411 x 345 x 60 mm 449 x 374 x 60 mm
13" x 10.5" x 2.2" 15.2"x 12.1"x 2.4" 16.2" x 13.6" x 2.4" 17.7" x 14.7" x 2.4"
Weight N.W. 4.7kgs / 10.4 lbs N.W. 5.8 kgs / 12.8 lbs N.W. 7.6 kgs / 16.7 lbs N.W. 9 kgs / 19.8 lbs
Mounting 100mm x 100mm Standard VESA / Panel Mount
OS Support Windows XP, WEPOS, XP Embedded, XP professional for Embedded, WIN 2000 professional Embedded, Linux
