Note: Before removing and replacing the PCMCIA holder,
make sure that the PCMCIA cards are removed and
the eject levers are sticking out.
1120 Auxiliary Antenna
v “1010 Battery assembly” on page 163
v “1020 Mini-PCI cover and Mini-PCI card” on page 163
v “1030 Memory cover and Memory card” on page 165
v “1060 Keyboard” on page 167
v “1080 Middle cover” on page 170
v “1090 LCD assembly” on page 171
v “1070 Backup battery” on page 114
v “1100 Keyboard bezel” on page 173
1
Step Size (Quantity) Color Torque
1 M2.5 x L5(1) Silver 2.5 kgf-cm
1130 Fan assembly
v “1010 Battery assembly” on page 163
v “1020 Mini-PCI cover and Mini-PCI card” on page 163
v “1030 Memory cover and Memory card” on page 165
v “1060 Keyboard” on page 167
v “1080 Middle cover” on page 170
v “1090 LCD assembly” on page 171
v “1070 Backup battery” on page 114
v “1100 Keyboard bezel” on page 173
176 ThinkPad R30/R31 HMM
