36
Connecting
—Continued
With
(Remote Interactive) you can control the
DPS-10.5 by using the remote controller supplied with
your Integra
-compatible AV receiver.
Notes:
• Push the plugs in all the way to make a good connec-
tion.
• Use only
cables for
connections.
•
To use
you must make an analog audio connec-
tion (RCA) between the DPS-10.5 and Integra AV
receiver, even if they are already connected digi-
tally.
• The DPS-10.5 has two
sockets. You can connect
either one to the Integra AV receiver. The other socket
is for connecting additional
-compatible compo-
nents.
• Connect the DPS-10.5’s
socket to only Integra
components. Connecting to other manufacturer’s
components may cause them to malfunction.
You can use the following multiroom kits to control the
DPS-10.5 when it’s out of range of the remote controller:
• Multiroom kits such as those made by Niles and Xan-
tech.
Controlling the DPS-10.5 When It’s Out of
Range
If the DPS-10.5 is located in another room, installed in a
cabinet, or is out of range of its remote controller, you
can use a commercially available IR receiver to pick up
the remote controller signals and feed them to the
DPS-10.5, as shown below.
Connecting Components with
OUT
D. MIX
FRONT
SURR
1
CENTER
SURR
2
L
R
L
R
SUB
WOOFER
IN
REMOTE
CONTROL
VIDEO OUT
COMPONENT
S VIDEO
VIDEO
Y
P
B
P
R
1+ 2
1
RS
232
IR
SURR MODE
(AUDIO OUT)
IN
12
V
TRIGGER
Y
P
B
P
R
COAXIAL
OPTICAL
OPTICAL
COAXIAL
DIGITAL
1
DIGITAL
2
VIDEO
S VIDEO
HDMI
VIDEO IN
AUDIO OUT
HD VIDEO OUT
COMPONENT
AUDIO OUT
OUT
S400
( AUDIO)
OPTICAL
DIGITAL IN
OPTICAL
R
L
D. MIX
L
R
AUDIO OUT
AUDIO IN
REMOTE
CONTROL
REMOTE
CONTROL
Integra AV receiver
To use
you must
make an analog audio
connection (RCA)
between the DPS-10.5
and the other component
even if they are already
connected digitally.
cable
(supplied)
Controlling Components That Are
Out of Range
OUT
D. MIX
FRONT
SURR
1
CENTER
SURR
2
L
R
L
R
SUB
WOOFER
IN
REMOTE
CONTROL
VIDEO OUT
COMPONENT
S VIDEO
VIDEO
Y
P
B
P
R
1+ 2
1
RS
232
IR
SURR MODE
(AUDIO OUT)
IN
12
V
TRIGGER
Y
P
B
P
R
COAXIAL
OPTICAL
OPTICAL
COAXIAL
DIGITAL
1
DIGITAL
2
VIDEO
S VIDEO
HDMI
VIDEO IN
AUDIO OUT
HD VIDEO OUT
COMPONENT
AUDIO OUT
OUT
S400
( AUDIO)
OUT
IN
IR
IR IN
DPS-10.5
Inside
cabinet
Remote controller
Connecting
block
IR receiver
Signal flow
