Invacare 1384 - Manual

FIGURE 1 - SEAT INSTALLATION/REMOVAL
Elevated
Toilet Seat
Horizontal
Mounting
Bolts
Toilet Bowl
Mounting
Brackets
Vertical
Mounting
Bolts
OVER
Elevated Toilet Seat
Assembly, Installation and Operating Instructions
Model No. 1384
4. Loosen vertical mounting bolt with wrench provided.
5. Position adjustable elevated toilet seat onto toilet
bowl.
6. Twist or pivot each mounting bracket against toilet
bowl rim.
7. After all four (4) mounting brackets have been posi-
tioned properly, securely tighten ALL mounting bolts.
SEAT REMOVAL (FIGURE 1)
NOTE: Refer to the GENERAL WARNINGS in the
SAFETY SUMMARY of this instruction sheet.
1. Loosen horizontal mounting bolts on all four (4)
mounting brackets.
2. Lift up Elevated Toilet Seat off of the toilet bowl.
CLEANING PROCEDURES
WARNING
DO NOT use an abrasive detergent, cleaner or
cloth to clean/dry the Elevated Toilet Seat.
1. Use a non-abrasive detergent or cleaner with warm
water.
2. Rinse with warm water and wipe dry with a non-abra-
sive cloth.
SAVE THESE INSTRUCTIONS
NOTE: Check all parts for shipping damage. In case of
shipping damage, DO NOT use. Contact Dealer/Carrier
for further instruction.
SAFETY SUMMARY
The following recommendations are made for the safe
installation of the Elevated Toilet Seat:
GENERAL WARNINGS
DO NOT install this equipment without first read-
ing and understanding this instruction sheet. If you
are unable to understand these Warnings, Cau-
tions and Instructions, contact a healthcare pro-
fessional, dealer or technical personnel if appli-
cable before attempting to install this equipment
- otherwise, injury or damage may occur.
Always check to make sure that the Elevated
Toilet Seat is properly and securely locked in place
before using.
Ensure that all four (4) mounting brackets are ad-
justed to the same height-otherwise injury or dam-
age may occur.
Be sure to center your weight on the Elevated
Toilet Seat because the seat may tip if you lean
too far forward or to either side.
Users with limited physical capabilities should be
supervised or assisted when using the Elevated
Toilet Seat.
The Elevated Toilet Seat has a recommended
weight limitation of 250 lbs.(114 kg.).
SEAT INSTALLATION (FIGURE 1)
NOTE: Refer to the GENERAL WARNINGS in the
SAFETY SUMMARY of this instruction sheet.
1. Remove contents from the carton.
NOTE: There are three (3) height adjustment positions.
The Elevated Toilet Seat is shipped in the middle position.
2. Remove two (2) horizontal mounting bolts and ad-
just bracket to desired height. Finger tighten only.
Repeat for remaining three (3) brackets.
3. Visually inspect that all four (4) mounting brackets
are adjusted to the same height.
