7/4/2004 Page 6 of 22
•
Attach VCon IGC server T1 link to NSU, DSU or Embedded PRI card
o Configure hardware for Line Termination through jumpers or DIP
switch – please refer to the Technician’s Handbook of the correct
product (3300 or SX2000)
•
connect to server with a straight through cable
•
Program trunks
o for example, please see Example of T1/D4 Programming on 3300
or SX2000
•
Test link to server by dialing
access> < # > e.g.
<**2><6101><1000><#>
o You should hear “Welcome to Remoteability”
•
Program ARS so a single four digit number accesses the IGC system
o Program trunk group
o Add trunks to trunk group
o Create Digit Modification Assignment ** see following note
o Create Route Assignment
o Create ARS Digits Dialed Assignment
o Please see Example of ARS Programming on 3300 or SX2000
**Note: The Dialogic card in the IGC server is expecting ANI on the T1D4
trunk, but the 3300 or SX2000 does not deliver ANI over T1D4. This will
result in a 10 to 15 second delay in accessing the IGC after the trunk
access number is dialed. To correct this, send an ANI digit string to the
trunk through the Digit Modification Form. See below.
Digit Modification Assignment
Digit
Modification
Number Number of
Digits to
Absorb
Digits to be
Inserted
Final Tone
Plan/Information
Marker
1 3
2 0
3 1
4 0 **6135922122**
Example of T1/D4 (CAS) Programming on 3300 or SX2000
Class Of Service – changes from default values
Public Network Access via DPNSS
Yes
