39. Attach the Low Cable (59) to the “U”-Bracket (33)
with an M6 Washers (62) and an M6 Locknut
(80). Do not completely tighten the Locknut; it
should be threaded onto the end of the Cable
until only two threads are showing above the
Locknut, as shown in the inset drawing.
39
15
80
62
33
40. Make sure all parts of the weight bench are properly tightened. In addition, pull each cable a few
times to make sure the cables move smoothly over the pulleys. If the cables do not move smoothly,
locate and correct the problem. When weights are used, the cables may be damaged if they are
incorrectly routed. Refer to the CABLE DIAGRAMS on page 19 for correct cable routing.
The use of all remaining parts will be explained in ADJUSTMENTS, beginning on the following page.
59
59
33
80
