TIPS FOR ASSEMBLY OF YOUR
NEW MANTEL
• Before you begin assembly, locate the instructions and hardware. Take out all the parts and
compare them to the diagrams below. Be sure you have all the parts and can identify them.
• A helping hand is always good: assemble your mantel with an adult assistant if possible. Some
pieces are heavy and will need to be held by a helper. Assembly time will be approximately
30-60 minutes.
• Locate a good Phillips-head screwdriver. You may also use an electric screwdriver but be careful not
to strip the head of the screw by over tightening them.
TOP 1 PC
288CH.01
RIGHT SIDE PANEL
288CH.02
BASE 1 PC
288CH.03
FRONT CENTER PANEL 1 PC
288CH.04
RIGHT FRONT PANEL 1 PC
288CH.05
LEFT SIDE PANEL 1 PC
288CH.06
LEFT FRONT PANEL 1 PC
288CH.07
BACK PANEL 2 PCS
288CH.08
HARDWARE LIST
A Bolts 20PCS
B Flat Washers 20PCS
C Wood Dowels 20PCS
D Wood Screws 14PCS
