Creating RAID Volume
Step 1:
In the RAID Setup window, press to create RAID volume (Figure 3).
Step 2:
Then, use number keys 1~3 to select a RAID type: (1)JBOD, (2)RAID 0, or (3)RAID 1 and then press
(Figure 4). In the following procedure, we'll create RAID 0 as an example.
SiS RAID BIOS Setting Utility
RAID Setup
* Current Created Raid *
Press [A] key to create RAID
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 ST3120026AS 111GB UDMA 6 Single
Disk 2 ST3120026AS 111GB UDMA 6 Single
SiS RAID BIOS Setting Utility
RAID Setup
* Current Created Raid *
RAID Type : <1> JBOD <2> RAID 0 <3> RAID 1 :
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 ST3120026AS 111GB UDMA 6 Single
Disk 2 ST3120026AS 111GB UDMA 6 Single
Figure 3
Figure 4
