TIPS FOR ASSEMBLY OF YOUR
NEW MANTEL
• Before you begin assembly, locate the instructions and hardware. Take out all the parts
and compare them to the diagrams below. Be sure you have all the parts and can identify them.
• A helping hand is always good: assemble your mantel with an adult assistant if possible. Some
pieces are heavy and will need to be held by a helper. Assembly time will be approximately
30-60 minutes.
• Locate a good Phillips-head screwdriver. You may also use an electric screwdriver but be careful not
to strip the head of the screw by over tightening them.
• After you assemble your mantel, if you find you have interference between the door and the hearth
please see Step 6 of these installation instructions for the solution.
NOTE: 284SOK = Oak Finish, 284SCH = Cherry Finish
TOP 1PC
284SOK.14/284SCH.14
BASE 1PC
284SOK.01/284SCH.01
LEFT SIDE PANEL
(EXTERIOR) 1PC
284SOK.02/284SCH.02
RIGHT SIDE PANEL
(EXTERIOR) 1PC
284SOK.03/284SCH.03
LEFT SIDE PANEL
(INTERIOR) 1PC
284SOK.03/284SCH.03
RIGHT SIDE PANEL
(INTERIOR) 1PC
284SOK.05/284SCH.05
TOP SHELF 2PCS
284SOK.06/284SCH.06
BASE SHELF 2PCS
284SOK.07/284SCH.07
CENTER PANEL 1PC
284SOK.09/284SCH.09
FIREBOX SHELF 1PC
284SOK.11/284SCH.11
BACK PANEL 2PCS
284SOK.08/
284SCH.08
LEFT DOOR 1PC
284SOK.12/
284SCH.12
RIGHT DOOR 1PC
284SOK.13/
284SCH.13
ANTI-TIP DEVICE 2 SETS
1 1 4 4
LOWER CENTER
PANEL 1PC
284SOK.10/284SCH.10
SHELF 8PCS
284SOK.15/284SCH.15
