2. HORIZONTAL MODE
2-10
2.9
Finding Echo Position with the Cursor
The cursor measures horizontal range, depth and bearing. Operate the Omnipad to place
the cursor where desired. Cursor position data appears at the top left-hand corner on the
screen.
→
: Horizontal range
↓
: Depth
B: Bearing
Cursor position data
Cursor
NAV
DATA
Location of cursor position data
