Furuno MFDBB - Manual

PUB. NO. MLG-44440-B
(0807, DAMI) MFD8/12/MFDBB
The purpose of this Operator’s Guide is to provide basic operating procedures for this equip-
ment. For more detailed information see the Operator's Manual
.
General
Power on/off
Selecting a display
Chart, radar orientation
Selecting a range Scrolling the chart, radar picture
• Press RANGE OUT to
increase the range.
• Press RANGE IN to decrease
the range.
Press arrow or diagonal to
scroll chart, radar picture. To re-
center own ship, push SHIP/3D
button.
Operator's Guide
MULTI FUNCTION DISPLAY
MFD8/MFD12/MFDBB
ON: Momentary push
OFF: Long push (3 sec.)
Select
display.
DISP
OUT
IN
RANGE
SHIP
3D
SCR
OLLING
Select
orientation soft
control.
Select
orientation.
Confirm
selection.
Head Up
Course Up
North Up
Confirm
selection.
North
Up
Course
Up
Long
push
