FireplaceXtrordinair 44 DV XXL EF - Manual (Page 32)

3 2
Finalizing the Installation
(for qualified installers only)
Travis Industries 4050114 1 0 0 - 0 1 1 4 9
(b) Place the Middle Logs
Line up the hole in the left
middle log with this pin.
After placing the logs, push them backwards
to the outside edges contact the rear log
Line up the two holes in the right
middle log with these bolts (or pins)
