Upgrading main memory
A26361-D1562-Z120-2-6319 English - 21
533 333 333 266
400 266 266 266
Installing a memory module
2
2
Ê Push the holders on each side of the memory slot outwards.
Ê Insert the memory module into the location (1).
Ê At the same time flip the lateral holders upwards until the memory module snaps in place (2).
Removing a memory module
1
1
Ê Push the clips on the right and left of the memory slot outward (1).
Ê Pull the memory module out of the memory slot (2).
