Fujitsu TE988G Color Monitor
4
Installation
Tilt Swivel & Base
1. Turn the monitor upside down.
2. Turn the base upside down. Insert its four hooks into the four slots on the bottom of the
monitor. (Point the hooks on the base toward the front of the monitor)
Figure 1
3. Push the tilt swivel and base in the direction of arrow (
!) as indicated in Figure 2 to
lock the hooks.
Figure 2
