Fisher 657 - Manual (Page 19)

Instruction Manual
D100307X012
657 Size 80 and 100 Actuators
December 2010
19
Key 6 Size 80 Actuator Spring, steel
SIZE
COMPRESSION
RATE
MAXIMUM
LOAD PART
NUMBER
COLOR
CODE
Lb/in N/mm Lb N
80
335
1000
1650
2100
2600
3100
58.7
175.1
288.9
367.7
455.3
542.8
2480
5630
7900
10,600
10,600
13,800
11,031
25,042
35,139
47,148
47,148
61,382 1J518227082
1H747727082
1H747527082
1H747327082
1H747627082
1H747027082
White
Red
Lt. Blue
Yellow
Lt. Green
White
Key 6 Size 100 Actuator Spring
GROUP
COMPRESSION
RATE
MAX LOAD
PART
NUMBER
COLOR
CODE
Lb/in N/mm Lb N
1
33‐1/4 Inch (844 mm)
Free Length
1775
2950
4500
6000 310.8
516.5
787.9
1050.6
17,500
25,000
36,000
45,000 77,840
111,200
160,128
200,160
10A2561X012
10A2562X012
10A2563X012
10A2564X012 None
None
None
None
2
16‐1/2 Inch (419 mm)
Free Length
335
1000
1650
2100
2600
3100
58.6
175.1
288.9
367.7
455.2
542.8
2480
5630
7900
10,600
10,600
13,800
11,031
25,042
35,139
47,148
47,148
61,382 1J518227082
1H747727082
1H747527082
1H747327082
1H747627082
1H747027082
Brown
Red
Blue
Yellow
Green
White
Figure 6. Top‐Mounted Handwheel for Size 80 Actuator
APPLY LUB
CV8009‐E
