7
Multi-Sector
Transfers: ■ Disabled
■ 2 Sectors
■ 4 Sectors
■ 8 Sectors
■ 16 Sectors
■ 32 Sectors
■ 64 Sectors
■ 128 Sectors
[16 Sectors] This option cannot be changed when Auto is selected. Specify the
number of sectors per block for multiple sector transfer. MAX refers
to the size the disk returns when required.
LBA Mode Control: ■ Disabled
■ Enabled
[Enabled] Enables or disables logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when Auto
is selected.
PIO Transfer Mode: ■ Standard
■ Fast PIO 1
■ Fast PIO 2
■ Fast PIO 3
■ Fast PIO 4
[Fast PI0 4] Selects the method for moving data to/from the drive. Autotype the
drive to select the optimum transfer mode. This option cannot be
changed when Auto is selected. Multi-word DMA is automatically
set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3, and set to
mode 2 for Fast PIO 4 / DMA.
DMA Transfer
Mode: ■ Disabled
■ Multiword DMA 1
■ Multiword DMA 2
■ Ultra DMA 0
■ Ultra DMA 1
■ Ultra DMA 2
■ Ultra DMA 3
■ Ultra DMA 4
■ Ultra DMA 5
[Ultra DMA 5] Selects the method for moving data to/from the drive. Autotype the
drive to select the optimum transfer mode. This option cannot be
changed when Auto is selected.
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu
Menu Field Options Default Description
M a i n M e n u
