11
Table 4: Fields, Options and Defaults for IrDA Port Configuration Submenu of Advanced Menu
Menu Field Options Default Description
Infrared Port: ■ Disabled
■ Enabled
■ Auto
[Enabled] Configures the infrared port using either no configuration (Disabled), a
user defined configuration (Enabled), or by allowing the BIOS or OS to
choose the configuration (Auto).
Mode: ■ IrDA
■ FIR
[FIR] Select whether to use normal infrared or fast infrared mode.
I/O Address: ■ 3F8 - 3FF
■ 2F8 - 2FF
■ 3E8 - 3EF
■ 2E8 - 2EF
[2E8 - 2EF] Allows user to set the infrared port base I/O address when infrared port is
Enabled.
Interrupt: ■ IRQ 3
■ IRQ 10
■ IRQ 11
[IRQ 3] Allows user to set the infrared port interrupt when infrared port is Enabled.
I/O Address: ■ 400 - 43F
■ 480 - 4BF
■ 500 - 53F
■ 580 - 5BF
[400 - 43F] Allows user to set the infrared port I/O address when FIR is Enabled.
DMA Channel: ■ DMA 1
■ DMA 3
[DMA 3] Allows user to set the infrared port DMA Channel when the infrared port
is Enabled.
A d v a n c e d M e n u
