MIDI In/Out Data Format
VM200 User’s Guide
221
1-20:Ch 0x7f:All
0:off 1:on
<< CH1-20 – Phase >>
command: f0 51 19 10 21 f7.
request: f0 51 29 10 21 f7.
status:
f0 51 39 10 21 f7.
1-20:Ch 0x7f:all_Ch
0:Nor. 1:Inv.
<< CH1-20 – S/P DIF In>>
command: f0 51 19 10 26 f7.
request: f0 51 29 10 26 f7.
status:
f0 51 39 10 26 f7.
1-20:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 – Rout:ST Buss >>
command: f0 51 19 10 30 f7.
request: f0 51 29 10 30 f7.
status:
f0 51 39 10 30 f7.
1-20:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 – Rout:REC Buss >>
command: f0 51 19 10 31 f7.
request: f0 51 29 10 31 f7.
status:
f0 51 39 10 31 f7.
1-20:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 : Adat Direct >>
command: f0 51 19 10 33 f7.
request: f0 51 29 10 33 f7.
status:
f0 51 39 10 33 f7.
1-8:Ch 0x7f:all_Ch
0:off 1:on
<< CH1-20 – Aux Send Level >>
command: f0 51 19 10 41 f7.
request: f0 51 29 10 41 f7.
status:
f0 51 39 10 41 f7.
1-20:Ch 0x7f:all_Ch
1:aux1 2:aux2 3:aux3 4:aux4 0x7f:all_aux
0-127:Vol
<< CH1-20 – Aux Post/Pre >>
command: f0 51 19 10 43
f7.
request: f0 51 29 10 43 f7.
status:
f0 51 39 10 43
f7.
0x7f:all_Ch
1:aux1 2:aux2 3:aux3 4:aux4 0x7f:all_aux
0:post 1:pre
<< CH1-20 – Eff Send Level >>
command: f0 51 19 10 49 f7.
request: f0 51 29 10 49 f7.
status:
f0 51 39 10 49 f7.
1-20:Ch 0x7f:all_Ch
1:eff1 2:eff2 0x7f:all_eff
0-127:Volume
<< CH1-20 – Eff Post/Pre >>
command: f0 51 19 10 4b
f7.
request: f0 51 29 10 4b f7.
status:
f0 51 39 10 4b
f7.
0x7f:all_Ch
1:eff1 2:eff2 0x7f:all_eff
0:post 1:pre
<< CH1-20 – Eq On >>
command: f0 51 19 10 50
f7
request: f0 51 29 10 50 f7
status:
f0 51 39 10 50
f7
1-16:Ch 0x7f:all_Ch
0x7f:all Band.
0:off 1:on
<< CH1-20 – Eq Type(Q) >>
command: f0 51 19 10 51 f7
request: f0 51 29 10 51 f7
status:
f0 51 39 10 51 f7
1-16:Ch 0x7f:all_Ch
1:L 2:LM 3:HM 4:H 0x7f:All_Band.
0:Hi/Lo_pass 1:Shelving 2-46:Parmetric_Q
<< CH1-20 – Eq Gain >>
command: f0 51 19 10 52 f7
request: f0 51 29 10 52 f7
status:
f0 51 39 10 52 f7
1-16:Ch 0x7f:all_Ch
1:L 2:LM 3:HM 4:H 0x7f:All_Band.
0-72:gain (36:0dB)
<< CH1-20 – Eq Freq >>
command: f0 51 19 10 53
f7
request: f0 51 29 10 53 f7
status:
f0 51 39 10 53
f7
1-16:Ch 0x7f:all_Ch
1:L 2:LM 3:HM 4:H 0x7f:all_Band.
(lower 7bit) + (upper 7bit) 0-239:F step.
<< CH1-20 – Eq Lib Recall >>
command: f0 51 19 10 5e f7
1-16:Ch 0x7f:All
0-99:Eq lib number.
