FUJITSU FMC-8FX FAMILY MB95F430 User Manual

Induction heater hardware user manual

background image

FUJITSU MICROELECTRONICS (SHANGHAI) CO., LTD.

Unit 1501, Jin Mao Tower, 88 Century Ave., Pudong New Area, Shanghai, P.R. China
Tel: 61007800 Fax: 61007802

MCU-AN-500087-E-12


F²MC-8FX FAMILY

8-BIT MICROCONTROLLER

MB95F430 SERIES




Induction Heater Hardware

User Manual




Revision History

Version

Date

Comment

Charge

1.0

2010-04-06

Create.

Folix

1.1

2010-08-11

Modified:
1. System Feature;
2. MCU Pin Assignment;
3. IGBT Feature;
4. Power Module;
5. IGBT Driver Module;
6. Pad Driver Module;
7. Main Board SCH;

Folix

1.2

2010-9-10

Update operation description

Terry
