FUJITSU V3525 - Manual (Page 2)

Data Sheet
⏐ Issue: January 2007⏐ AMILO Pro V3525/V3545 Edition
Page 2 / 3
System AMILO Pro V3525 Edition AMILO Pro V3545 Edition
Processor
Intel® Core 2™ Duo Processor up to T7600 up to T7600
Second level cache 4 MB 4 MB
Front side bus (FSB) 667 MHz 667MHz
Intel® Core™ Duo Processor T2250, T2400 T2250, T2400
Second level cache 2 MB 2 MB
Front side bus (FSB) 533 / 667 MHz 533 / 667 MHz
Intel® Celeron M™ Processor M520 M520
Second level cache 1 MB 1 MB
Front side bus (FSB) 533 MHz 533 MHz
Chipset
Northbridge Intel 945GM Intel 945PM
Southbridge ICH 7-M ICH 7-M
Memory
DDR2-533 SDRAM, 533 / 667 MHz
up to 2 GB
(maximum 4 GB supported
with future modules )
up to 2 GB
(maximum 4 GB supported
with future modules )
DIMM slots 2 2
BIOS
BIOS Flash EPROM Phoenix First BIOS Phoenix First BIOS
Interfaces
Type I/II PC Card slot 1 1
3in1 Card Reader (SD, MMC and memory stick) 1 1
USB 2.0 4 4
S-Video out (TV-out) 1 1
VGA 1 1
Modem RJ-11 1 1
LAN RJ-45 1 1
Audio-in (line-in / microphone) 1 1
Audio-out (line-out / headphone) 1 1
DC-in 1 1
Kensington Lock 1 1
Modem on board
56K V.92 modem MDC1.5 x x
LAN on board
built-in 10/100/1000 Mbps Marvell 88E8055 x x
Wireless Technologies (WLAN)
Import and usage according to country-specific regulations.
Dual band antenna
Intel PRO/Wireless 3945 a/b/g x x
Integrated UMTS (HSDPA 1.8 Mb/s), also supported are GPRS and EDGE optional optional
Bluetooth
Bluetooth V2.0 optional optional
Audio
Stereo speakers x x
Sound chip RealTek ALC861 RealTek ALC861
Internal microphone x x
Keyboard and pointing device
Keyboard
85 keys, 19mm pitch,
2.5mm key stroke
85 keys, 19mm pitch,
2.5mm key stroke
Touchpad with two mouse buttons with two mouse buttons
Launch keys 2 keys 2 keys
Status LED x x
Graphics
Intel GMA 950 with 256-bit graphics core with dynamic video memory
technology up to 224MB, 32-bit color depth
x -
NVIDIA GeForce Go 7300 128 MB VRAM (up to 512 MB Turbo Cache) - x
Direct X9 x x
Pixelshader 2.0 x x
DualView (Windows XP) x x
Display
15.4-inch TFT WXGA / 1280 x 800 pixel x x
Max. resolution for external displays
1600 x 1200 / true color /
85 Hz
1600 x 1200 / true color /
85 Hz
Hard disk drives (internal) *
Up to 160 GB S-ATA 150 (5400 rpm) x x
* 1 Gbyte equals one billion bytes, when referring to hard disk drive
capacity; accessible capacity may vary, also depending on used software
and tool.
Fixed drives
DVD+/- RW Dual layer (+R) Multiformat DVD writer with
double layer support
x x
Manageability
Supported Standard
PXE x x
