F i n i s a r

Finisar Corporation PRELIMINARY and Confidential Page 1
Rev C, February 2005
Preliminary Product Specification
DWDM SFP Transceiver
FWDM-1629-XX
PRODUCT FEATURES
•
Up to 1.25 Gb/s bi-directional data
links
•
Hot-pluggable SFP footprint
•
Temperature-stabilized DWDM-
rated DFB laser transmitter
•
100GHz ITU Grid, C Band
•
Low dispersion DFB laser suitable
•
Metal enclosure for low EMI
•
Extended operating range: -5°C to
70°C case temperature
•
Wavelength controlled within
±
0.1
nm over life and temperature
•
Extended link budget with APD
receiver technology
•
GbE and 1X FC compliant
APPLICATIONS
•
Amplified DWDM networks
•
Bandwidth aggregation
•
Ring topologies with OADM
Finisar’s Dense Wavelength-Division Multiplexing (DWDM) transceivers offer DWDM
transport with dramatically lower power and cost in a standard pluggable Small Form
Factor Pluggable (SFP) package. The FWDM-1629 is designed expressly for service
providers deploying DWDM networking equipment in metropolitan Ethernet and SAN
networks. The fiber link budget has been enhanced to 30dB with an Avalanche Photo
Diode (APD) receiver.
In addition, digital diagnostic features are implemented as described in Finisar
Application Note AN-2030, “Digital Diagnostic Monitoring Interface for Optical
Transceivers”
