SERVICING YOUR TILLER
25
Fuel Tube Inspection
Check the fuel supply and return tubes, and replace
any tube that is damaged, cracked, or leaking.
Refer to the Honda shop manual for tube replacement
instructions, or take the tiller to an authorized Honda
servicing dealer.
Fuel Filter and Fuel Tank Cleaning
1. Remove the fuel tank cap.
2. Tip the tiller as shown and empty the fuel tank into
an approved gasoline container. Use a funnel to
avoid spilling gasoline.
3. Pull the fuel filter out through the fuel filler neck by
hooking the black fuel supply tube with a piece of
wire, such as a partly straightened paper clip.
4. Inspect the fuel filter. If the fuel filter is dirty, wash it
with nonflammable solvent. Be careful to avoid
damaging the filter.
5. Replace the filter if it is damaged or excessively
dirty.
6. Rinse sediment from the fuel tank with
nonflammable solvent.
7. Insert the fuel filter in the fuel tank, and install the
fuel tank cap.
FUEL
SUPPLY
TUBE
(black)
FUEL
RETURN
TUBE
(clear)
FUEL
TANK
CAP
FUEL
TANK
FUEL
FILTER
WIRE
FUEL
SUPPLY
TUBE (black)
FUEL FILTER
