ENGLISH
SETTING ENGINE SPEED STOPPING THE ENGINE
O O F F F F
ENGINE SWITCH
THROTTLE LEVER
O O F F F F
FUEL VALVE LEVER
MAX.
M M I I N N . .
THROTTLE LEVER
M M I I N N . .
O O F F F F
O O F F F F
M M I I N N . .
MAX.
MIN.
5
Position the throttle lever for the desired engine speed.
Some engine applications use a remote-mounted throttle control
rather than the engine-mounted throttle lever shown here.
For engine speed recommendations, refer to the instructions
provided with the equipment powered by this engine.
To stop the engine in an emergency, simply turn the engine switch
to the OFF position. Under normal conditions, use the following
procedure.
Some engine applications use a remote-mounted throttle
control rather than the engine-mounted throttle lever shown
here.
Turn the engine switch to the OFF position.
Turn the fuel valve lever to the OFF position.
Move the throttle lever to the MIN. position.
2.
3.
1.
