4600g, 4600r, 4800i User’s Guide 1 - 13
Each of the previous bar codes also programs the following suffixes for each
symbology:
.
The IBM 4683 Port 9B HHBCR-2 Interface bar code also programs the following
suffixes for each symbology:
Wand Emulation Connection
Note: See "Imager Models" on page 1-2 to determine which interfaces apply to
your imager.
In Wand Emulation mode, the imager decodes the bar code then sends data in
the same format as a wand imager. The Code 39 Format converts all
symbologies to Code 39.
The Same Code Format transmits UPC, EAN, Code 128, Codabar, and
Interleaved 2 of 5 without any changes, but converts all other symbologies to
Code 39. 2D symbologies are converted to Code 128.
Symbology Suffix
EAN-8 0C
EAN-13 16
UPC-A 0D
UPC-E 0A
Code 39 00 0A 0B
Interleaved 2 of 5 00 0D 0B
Code 128 00 0A 0B
Symbology Suffix
EAN-8 0C
EAN-13 16
UPC-A 0D
UPC-E 0A
Code 39 00 0A 0B
Interleaved 2 of 5 00 0D 0B
Code 128 00 18 0B
IBM 4683 Port 9B HHBCR-2 Interface
