4600g, 4600r, 4800i User’s Guide
13 - 7
USB
10 Pin Modular Plug
connects to the imager handle
1
2D
a
ta
+
3
T
ied to 5 volt power
4
S
upply ground
5
6
7
5
volt power connection
8
9
10
Data -
