4600g, 4600r, 4800i User’s Guide
13 - 5
Wand Emulation
10 Pin Modular Plug
c
onnects to the imager handle
1
2
Cord shield
3
T
ied to 5 Volt power
4
S
upply ground
5
6
B
ar code data output
7
5
Volt power connection
8
9
10
9 Pin T
y
pe
D Fe
male
connects to your terminal
1
2
3
4
5
6
7
8
9
Supply ground
Cord shield
5 Volt power
connection
Bar code data output
