13 - 4 4600g, 4600r, 4800i User’s Guide
Standard Cable Pinouts
Keyboard Wedge
10 Pin RJ41 Modular Plug connects to the imager handle
1 2
C
ord shield
3P
ro
g
1
4
S
upply ground
5
T
erminal clock
6
T
erminal data
7
P
ower connection (Refer to table on
page
13-1
)
8
K
eyboard data
9
K
eyboard clock
10
