SPECIFICATIONS / MAIN FEATURES
1
5
8
9
10
11
12
13
6
4
3
2
7
Code 616
Engine Briggs & Stratton
Engine type Series 500
Engine / Cutterbar Speed 2850 rpm
Fuel type Unleaded petrol
Fuel capacity 1.5 litres
Oil type SAE 30 engine oil
Oil sump capacity 0.6 litres
Cutting width 410mm
Cutting height 13 - 65mm
Overall dimensions 1050 x 472 x 1370mm
Weight 30 Kg
1. Air Cleaner.
2. Engine Cover
3. Oil Filler Cap and Dipstick.
4. Serial No. Label.
5. Handlebar Securing Knob.
6. Engine Start Grip.
7. Engine Stop Lever.
8. Upper Handlebar.
9. Grassbag.
10. Rear Deflector.
11. Height Of Cut Adjuster.
12. Exhaust Guard.
13. Spark Plug Lead.
