33
ON-SCREEN DISPLA
Y
Audio
Select Audio to adjust the sound to your preference.
Sound Mode
This function has four sound modes that are preset according
to the type of program. Standard is for normal audio conditions,
Movie audio settings is for movies, News audio settings is for
News programs and Custom mode is for adjusting audio levels
to your preference. The only mode that can be directly changed
by adjusting any audio setting to your desired conditions is the
Custom mode. The other modes are preset and any changes made
to these modes will be applied to Custom mode.
Audio Menu Settings Adjustment
Press the CURSOR PAD 1. or to select menu item.
Press the CURSOR PAD 2. or to adjust the function.
Press EXIT to quit the MENU, or select AUDIO to return to the 3.
main menu.
If Treble is selected you are adjusting treble.
The additional menu items Bass and Balance can be
selected and adjusted in the same manner.
Bass
This function controls the low frequency audio to the speakers.
Treble
This function controls the high frequency audio to the speakers.
Balance
This function will control the left to right balance of the LCD TV
internal speakers and headphone jack.
CONEQ
Delivers clear crisp sound and hi fidelity music playback.
Use CURSOR 1. to select the preferred setting.
Defeat : This mode is for bypassing sound equalizer.
Table Top: Use this setting for improved sound quality with
table top stands.
Wall Mount: Select this setting for improved sound quality
when wall mounting.
Hearing Aid: This special mode is for users that want to
maintain clear sound after removing their conventional hearing
aid. Note that this feature emphasizes higher frequencies.
SRS TruSurround HD
Provides enveloping, impressive surround sound, for every seat in
the room using only the TVs internal speakers.
Use CURSOR 1. to select On/Off option.
Off : Turns off the surround sound effect.
On: : Provides the surround effect by simulating two or more
speakers to the rear of the listener.
If
T
s
NOTE
Audio Source
Multi-Channel Television Sound will allow you to select STEREO (a
stereo broadcast), MONO (monaural sound) used when receiving
a weak stereo broadcast or SECOND AUDIO PROG (SAP) which
may be a secondary language, weather report, etc. This setting is
only for analog programing.
Preferred Language
Some programs transmit in other languages. This language function
will allow you to set between 3 language options (English,Español
& Français) to your preference as the audio default language.
Audio Language
Some programs transmit more than one DTV language option. Most
will have English as a default language. The language function will
allow you to select up to 6 language options (if available). Please
try all available options.
Digital Output
This function allows you to select between RAW and PCM.
This setting changes the format of the Digital Optical Output.
PCM.- Select this feature if the TV is connected to an amplifier/receiver
with a PCM only decoder; it will provide two independent soundtrack
channels through the optical audio output jack (Digital Audio).
RAW.- Select this feature to allow the original audio bit stream to
be passed through to the audio receiver.
Internal Speakers
This function is useful when using external speakers. Select ON if
using the internal speakers only. Select OFF if you prefer to use the
speakers from a separate stereo system.
Perfect Volume
This function will automatically adjust volume so each channel and
input has the same average volume level.
Reset
This function allows you to Reset the Audio Menu Settings
of the present input and return it to the Custom mode and
default settings.
Use the CURSOR PAD 1. , to highlight functions.
Press the SELECT button or the CURSOR PAD 2. to select
Yes or No.
Press the SELECT button on the Yes option to execute the
3.
reset of the Audio settings.
You can customize each of the Audio Inputs to your preference
to increase audio performance and pleasure, depending upon the
audio program being heard. If RESET is selected, only the present
Input will reset to the initial conditions as explained above.
If RESET is selected in HDMI1, only HDMI1 will return to
factory conditions.
Video
Audio
Treble
Select SEL
Channels
Sound Mode
Balance
Setup
Bass 50
Custom
0
50
Digital Output RAW
EXIT Exit Move Return
CONEQ Table Top
SRS TruSurround HD Off
Multimedia
Video
Audio
Select SEL
Channels
Setup
EXIT Exit Move Return
Digital Output RAW
Audio Language English1
Preferred Language English
Reset
Internal Speakers On
Perfect Volume On
Audio Source Stereo
Multimedia
