L-Series LCD Monitor User Manual
Document 800-00945 Rev A
11
09/07
Controls and Functions
The HMLCD17L and HMLCD19L monitors include the following features:
•
OSD menu
•
MPR II certified
•
DDC1 and DDC2 plug and play functionality
•
Full range power supply that auto adjusts to accept AC 100V to 240V and 50Hz to
60Hz
Front Panel Controls
Figure 1
Front panel controls
1.
AUTO button
2.
OSD t button
3.
OSD s button
4.
OSD MENU button
5.
Power switch
6.
LED Power indicator
1
2
3
4
5 6
1
2
3
4
5
HMLCD17L
HMLCD19L
