Systems Insight Display
The Systems Insight Display LEDs represent the server and component layout.
LED Description
ONLINE SPARE
Off—No protection
Green—Protection enabled
Amber—Memory failure occurred
Amber (flashing)—Memory configuration error
MIRROR Off—No
protection
Green—Protection enabled
Amber—Memory failure occurred
Amber (flashing)—Memory configuration error
All other LEDs
Off—Normal
Amber—Failed or missing component
